F5 BIG-IP Administration Data Plane Concepts (F5CAB2) Sample Questions (Q10-Q15):

NEW QUESTION # 10
Which statement is true concerning the default communication between a redundant pair of BIG-IP devices?

Answer: B


NEW QUESTION # 11
The diagram below shows the TCP connection setup for an application.

Which of the following virtual server types applies? (Choose one answer)

Answer: C

Explanation:
Comprehensive and Detailed Explanation From BIG-IP Administration Data Plane Concepts documents:
The diagram illustrates a specific TCP handshake sequence where the BIG-IP system acts as a transparent forwarder rather than a full proxy. The key indicators that identify this as a Forwarding (IP) virtual server are as follows:
Initial Packet Processing: The diagram explicitly states that the LTM evaluates the packet looking only at the destination IP address. This is the fundamental characteristic of a Forwarding IP virtual server, which uses the system's routing table to make forwarding decisions instead of load balancing to a pool of members.
Handshake Sequence: Unlike a Standard virtual server, which completes the three-way handshake with the client (SYN, SYN-ACK, ACK) before initiating a separate connection to the server, the Forwarding IP virtual server passes the client's original SYN packet directly to the destination node.
Response Timing: The BIG-IP system waits for the SYN-ACK from the destination node before it sends a SYN-ACK back to the client. It essentially "passes through" the handshake signals while still maintaining a state entry in the connection table to track the flow.
Packet-by-Packet Logic: While it tracks the state, it does not perform address translation (unless SNAT is specifically configured) or deep packet inspection like a full proxy would.
Why other options are incorrect:
Standard virtual server: A Standard virtual server is a "full proxy." It would finish the handshake with the client first and only then open a second, independent TCP connection to the backend server.
Stateless virtual server: A stateless virtual server does not track connections in the connection table. The diagram shows the system meticulously passing sequence numbers ($seq_num$) and acknowledgment numbers ($ack_num$) between the two sides, which requires stateful tracking of the TCP flow.


NEW QUESTION # 12
Refer to the exhibit.

The network team creates a new VLAN on the switches. The BIG-IP Administrator creates a new VLAN and a Self IP on the BIG-IP device, but theservers on the new VLAN are NOT reachablefrom the BIG-IP device.
Which action should the BIG-IP Administrator take to resolve this issue? (Choose one answer)

Answer: D

Explanation:
For BIG-IP to send or receive traffic on a VLAN, that VLANmust be bound to a physical interface or a trunk. Creating a VLAN object and a Self IP alone isnot sufficientto establish data-plane connectivity.
From the exhibit:
* The VLAN (vlan_1033) exists and has a tag defined.
* A Self IP is configured and associated with the VLAN.
* However, traffic cannot reach servers on that VLAN.
This indicates aLayer 2 connectivity issue, not a Layer 3 or HA issue.
Whyassigning a physical interfacefixes the problem:
* BIG-IP VLANs do not carry traffic unless they are explicitly attached to:
* Aphysical interface(e.g., 1.1), or
* Atrunk
* Without an interface assignment, the VLAN is effectively isolated and cannot transmit or receive frames, making servers unreachable regardless of correct IP addressing.
Why the other options are incorrect:
* A. Set Port Lockdown to Allow AllPort Lockdown controls which services can be accessedon the Self IP(management-plane access), not whether BIG-IP can reach servers on that VLAN.
* B. Change Auto Last Hop to enabledAuto Last Hop affects return traffic routing for asymmetric paths. It does not fix missing Layer 2 connectivity.
* D. Create a Floating Self IP addressFloating Self IPs are used for HA failover. They do not resolve reachability issues on a single device when the VLAN itself is not connected to an interface.
Conclusion:
The servers are unreachable because the VLAN hasno physical interface assigned. To restore connectivity, the BIG-IP Administrator mustassign a physical interface (or trunk) to the VLAN, enabling Layer 2 traffic flow.


NEW QUESTION # 13
What is the result when a BIG-IP Administrator manually disables a pool member? (Choose one answer)

Answer: C

Explanation:
Comprehensive and Detailed Explanation From BIG-IP Administration Data Plane Concepts documents:
In BIG-IP LTM, a pool member state directly affects how traffic is handled at the data plane level. When a pool member is manually disabled, BIG-IP changes the member's availability state to disabled, which has specific and predictable traffic-handling consequences.
According to BIG-IP Administration Data Plane Concepts:
A disabled pool member:
Does not accept new connections
Continues to process existing non-persistent connections until they naturally close Is removed from load-balancing decisions, including persistence lookups Most importantly for this question:
Persistent connections
(such as those created using source-address persistence, cookie persistence, or SSL persistence) are not honored for a disabled pool member BIG-IP will not send new persistent traffic to a disabled member, even if persistence records exist Therefore, when a pool member is manually disabled, it stops processing persistent connections, while allowing existing non-persistent flows to drain gracefully.
Why the Other Options Are Incorrect:
B - Persistent connections are not honored for a disabled pool member
C - Existing connections are not immediately terminated when a pool member is disabled D - Only the disabled pool member stops accepting new connections, not all pool members Key Data Plane Concept Reinforced:
Manually disabling a pool member is a graceful administrative action that prevents new and persistent traffic from reaching the member while allowing existing connections to complete, which is critical for maintenance and troubleshooting scenarios.


NEW QUESTION # 14
A BIG-IP Administrator needs to have a BIG-IP linked to two upstream switches for resilience of the external network. The network engineer who is going to configure the switch instructs the BIG-IP Administrator to configure interface binding with LACP. Which configuration should the administrator use?

Answer: C

Explanation:
In BIG-IP terminology, aTrunkis the object used to implement Link Aggregation (IEEE 802.3ad/802.1AX).
When a network engineer refers to "interface binding" or "EtherChannel" with LACP, the BIG-IP equivalent is a Trunk.
* LACP (Link Aggregation Control Protocol):This is a protocol that allows the BIG-IP system to communicate with the upstream switches to negotiate the bundling of multiple physical links into a single logical link.
* Resilience and Redundancy:By creating a trunk that includes interfaces connected to two different switches (typically configured as a VPC, VSS, or MLAG cluster on the switch side), the administrator ensures that the BIG-IP remains reachable even if one physical interface or one switch fails.
* Data Plane Logic:The BIG-IP treats the trunk as a single Layer 2 interface. VLANs are then associated with the trunk rather than individual physical ports.
Why the other options are incorrect:
* Option B:Trunks aggregate physical interfaces. While VLANs are associated with trunks, the trunk configuration itself does not "list" MAC addresses of the switches; it uses LACP to negotiate the connection.
* Options C & D:Virtual Servers are Layer 4-7 objects used for traffic processing and load balancing.
They do not possess "LACP profiles," nor are physical interfaces or management IPs treated as pool members for the purpose of link aggregation.


NEW QUESTION # 15
......
